Solutions for Alibre

DST offers two ways to simulate your Alibre Design models with SimWise: SimWise Inside, which runs inside Alibre Design, and SimWise for Alibre, a standalone version of SimWise linked to Alibre. Both use the same proven SimWise technology and come as Motion, FEA and 4D products.

SimWise Inside: simulation inside Alibre Design

SimWise Inside puts the power of SimWise inside Alibre Design. Motion simulation and finite element analysis run in Alibre itself, as environments on the Alibre ribbon, so you simulate the Alibre model you are designing: no export, no second program, and no copy of the model to keep up to date. Bodies, units, materials and mass properties come straight from Alibre, Alibre mates become motion joints, and your simulation studies and results are saved inside the Alibre file with the geometry.

  • SimWise FEA Inside Alibre - Stress, vibration, buckling, heat transfer and frequency response of parts and assemblies, without leaving Alibre Design.
  • SimWise Motion Inside Alibre - Kinematic and dynamic motion of assemblies: Alibre mates become joints; add motors, springs, forces and 3D contact, then measure what happens.
  • SimWise 4D Inside Alibre - Motion, FEA and Durability together: the loads from the motion drive the stress analysis and the fatigue life, so you know whether it works, whether it breaks, and how long it lasts.

SimWise for Alibre: standalone simulation linked to Alibre

SimWise for Alibre is a special version of SimWise that works with Alibre Design Expert and Alibre Design Professional. It runs as its own program and transfers parts, assemblies and assembly mates from Alibre bi-directionally. Once in SimWise, simulation-specific information is added to build a functional operating prototype. If the Alibre model changes, the changes are sent from Alibre to SimWise and reflected in the SimWise model without affecting the simulation information already added.

Because SimWise for Alibre is a separate program, simulating does not use an Alibre license. An engineer can spend the day running simulations while the Alibre license is free for someone else to design with.

  • SimWise Motion for Alibre - rigid body dynamics of assemblies of moving parts from Alibre.
  • SimWise FEA for Alibre - linear static, normal modes, buckling, steady state and transient heat transfer, and combined thermal/structural analysis of parts and assemblies from Alibre.
  • SimWise 4D for Alibre - SimWise Motion and SimWise FEA for Alibre combined, plus the stresses that result from the dynamic loads computed by a motion simulation.

Which one is right for you?

 SimWise InsideSimWise for Alibre (standalone)
Where you work Inside Alibre Design, on the Alibre ribbon. In SimWise, its own program, linked to Alibre.
Alibre license Alibre is open while you simulate, so an Alibre license is in use. No Alibre license is used while you simulate.
The model One model: studies and results are saved in the Alibre file, and SimWise notices when the design changes. Parts, assemblies and mates are transferred to SimWise, and design changes are sent from Alibre to update the SimWise model.
Alibre versions Alibre Design 29.1 and later version 29 releases. See the system requirements. Alibre Design Expert and Alibre Design Professional.
Best for Designers who want to check their work as they design, without leaving Alibre. Analysts who simulate for long periods, and teams that share Alibre licenses.
Growing Need more? Full SimWise adds control system co-simulation, multi-CAD support, export to other simulation systems, and fatigue life calculations.

Both answer the questions "Does it Work?" and "Will it Break?" without building physical hardware or running physical tests, at a cost compatible with your Alibre licenses, and both are available with node-locked, dongle and network licenses.
